Minn Kota Adapter Cable for Connecting MEGA DI Trolling Motor to HELIX 7

Minn Kota MKR-MDI-2HB Adapter Cable (HELIX 7 G3/G4)

1852086
  • We have 2 in stock.
Shipping calculated at checkout.
Ships from Winnipeg Fast Canadian Shipping
No Customs Fees for Canadians
Authorized Service Center We Fix What We Sell

Compatibility:

✅ Compatible Humminbird Units
Designed EXCLUSIVELY for:
• HELIX 7 CHIRP MEGA DI GPS G3 / G3N
• HELIX 7 CHIRP MEGA DI GPS G4 / G4N
• HELIX 7 CHIRP MEGA SI GPS G3 / G3N (For DI signal only)
• HELIX 7 CHIRP MEGA SI GPS G4 / G4N (For DI signal only)

✅ Compatible Minn Kota Motors
Must have "Built-In MEGA Down Imaging" (MDI) in the nose cone:
• Terrova / Ulterra / Ultrex (MDI Models)

❌ NOT Compatible
• HELIX 8, 9, 10, 12, 15 (Require MKR-MDI-1)
• HELIX 5 (Does not support MEGA DI)
• Motors with "Universal Sonar 2" (US2) - Requires MKR-US2-8
• Motors with Built-In Side Imaging (MSI)

The Specific Link for HELIX 7

Don't force the wrong plug. The **Minn Kota MKR-MDI-2HB** is the specific adapter cable required to connect a Minn Kota trolling motor with **Built-In MEGA Down Imaging** to a **Humminbird HELIX 7** (G3 or G4 model).

Why do I need this?

Unlike the larger HELIX 9/10/12 units (which use the MKR-MDI-1), the HELIX 7 has a unique pin configuration for its MEGA Imaging port. This shielded adapter converts the 14-pin motor output to the specific 7-pin plug required by your HELIX 7 to display crystal-clear Down Imaging.

📦 Product Specs:

  • Part Number: 1852086 (MKR-MDI-2)
  • Motor Side: 14-Pin Female (threaded)
  • Unit Side: 7-Pin Male (HELIX 7 Specific)
  • Length: Approx. 12 Inches
  • Shielding: Interference-Free Construction
🍁 Why Buy from PTG Electronics?
We are Canada’s specialized marine electronics hub and authorized service center. Unlike American retailers, we stock our inventory in Winnipeg, Manitoba. You get your gear faster with zero customs fees or hidden duties.

Frequently Asked Questions

What is the difference between MKR-MDI-1 and MKR-MDI-2?

It is all about the head unit. The MKR-MDI-1 is for HELIX 8, 9, 10, and 12. The MKR-MDI-2 (this cable) is specifically for the HELIX 7. They are not interchangeable.

Will this work with my old US2 motor?

No. The Universal Sonar 2 (US2) uses a completely different connector. If your motor says "US2" or "Universal Sonar," you need the MKR-US2-8 adapter for a HELIX 7. This cable is only for the newer "MEGA Down Imaging" motors.

Does this support Side Imaging?

No. This cable transmits the Down Imaging and 2D Sonar signal only. If you have a Side Imaging motor (MSI) and want to connect it to a HELIX 7 SI unit, you need a different adapter (MKR-MSI-2).
